In the era of precision endovascular therapy, vascular access is no longer just about reaching a target—it’s about managing the entire intravascular route with accuracy, control, and flexibility. Microcatheters have evolved from passive delivery tubes to become active pathway management platforms, enabling clinicians to execute complex interventions with enhanced predictability.
This product series offers a tri-level solution across coronary, peripheral, and super-selective interventions, each category tailored to support distinct strategy layers in lesion navigation, targeted delivery, and procedural optimization.
Designed for CTO lesions, bifurcation access, and calcified segments, these models provide enhanced support and guidewire maneuverability through braided shaft reinforcement and PTFE inner lining. Ideal for controlled wire escalation and re-entry techniques.
Engineered for long-segment iliac, renal, or subclavian access, these catheters offer greater inner lumen volume, enhanced torque, and preloaded 0.021” guidewires for faster setup and easier crossing of chronic occlusions.
Designed for tumor embolization (TACE, BAE), uterine interventions, and tortuous small-caliber arteries, these catheters feature 2.1Fr distal tips and high tip flexibility to enable precise navigation and localized drug or embolic delivery.
| Category | Model | Length | Distal / Proximal OD | Guidewire Compatibility | Key Attributes |
|---|---|---|---|---|---|
| Coronary | MCS02-0 | 130cm | 1.6Fr / 2.3Fr | 0.014"–0.016" | Radiopaque tip, braided shaft |
| Coronary | MCS03-0 | 150cm | 1.6Fr / 2.3Fr | 0.014"–0.016" | Radiopaque tip, long reach |
| Peripheral | MCS02-6 | 130cm | 2.8Fr / 3.0Fr | 0.021" (preloaded) | High lumen flow, guidewire-included |
| Peripheral | MCS03-6 | 150cm | 2.8Fr / 3.0Fr | 0.021" (preloaded) | Extended access, torque balance |
| Super-selective | MCS02-2 | 130cm | 2.1Fr / 2.3Fr | 0.014"–0.017" | Tip flexibility, drug precision |
| Super-selective | MCS03-2 | 150cm | 2.1Fr / 2.3Fr | 0.014"–0.017" | For deep branch embolization |
MCS02-* models are optimized for standard-length procedures (130cm), including routine coronary or short peripheral access
MCS03-* models offer 150cm length for deep access cases, such as SFA recanalization or variant hepatic arteries
All models feature PTFE-lined lumens, stainless steel braided shafts, and 0.6mm radiopaque distal markers
Peripheral models come preloaded with 0.021" guidewires, minimizing setup time
Coronary: CTO re-entry, bifurcation wire support, retrograde tracking
Peripheral: Long lesion contrast mapping, renal/femoral artery crossing
Super-selective: TACE, UAE, BAE, distal arterial delivery in microvascular networks
We built this microcatheter portfolio to empower interventional strategy, not just facilitate access. Whether you're navigating a calcified lesion, delivering embolics to a liver segment, or crossing a multi-level occlusion—these catheters are built to act as procedural tools that respond to your planning, not just your hand.
Contact us for technical specs, samples, OEM partnerships, or catalog support.
