| Quantity: | |
|---|---|
LGAQS
OEM
| main parameter | AQS1.2 | AQS1.5 | AQS2.0 | AQS2.5 | AQS3.0 | AQS4.0 | AQS 5.0 |
| Chamber measurement LxWxH | 1500×680 ×1180 | 1900×680 ×1180 | 1700×1000 ×1200 | 2100×1000 ×1200 | 2500×1000 ×1200 | 3340×1000 ×1200 | 4200× 1000× 1200 |
| External measurement LxWxH | 1800×1420 ×2150 | 2200×1420 ×2150 | 2000×1880 ×2200 | 2400×1880 ×2200 | 2800×1880 ×2200 | 3650×1880 ×2200 | 4500× 1880× 2200 |
| Steam(kg) | 60 | 80 | 100 | 120 | 150 | 200 | 250 |
| Washing water(kg) | 680 | 800 | 1000 | 1200 | 1500 | 2000 | 2500 |
| Compressed air(m³) | 1 | 1.5 | 2 | 2.5 | 3 | 4 | 5 |
| Power(kw) | 4 | 4 | 5.5 | 5.5 | 6.5 | 7.5 | 9 |
| Net weight(kg) | 1800 | 2000 | 2200 | 2500 | 3000 | 3500 | 4350 |
| Design pressure(MPa) | 0.245 | ||||||
| Design temperature(℃) | 139 | ||||||
| main parameter | AQS1.2 | AQS1.5 | AQS2.0 | AQS2.5 | AQS3.0 | AQS4.0 | AQS 5.0 |
| Chamber measurement LxWxH | 1500×680 ×1180 | 1900×680 ×1180 | 1700×1000 ×1200 | 2100×1000 ×1200 | 2500×1000 ×1200 | 3340×1000 ×1200 | 4200× 1000× 1200 |
| External measurement LxWxH | 1800×1420 ×2150 | 2200×1420 ×2150 | 2000×1880 ×2200 | 2400×1880 ×2200 | 2800×1880 ×2200 | 3650×1880 ×2200 | 4500× 1880× 2200 |
| Steam(kg) | 60 | 80 | 100 | 120 | 150 | 200 | 250 |
| Washing water(kg) | 680 | 800 | 1000 | 1200 | 1500 | 2000 | 2500 |
| Compressed air(m³) | 1 | 1.5 | 2 | 2.5 | 3 | 4 | 5 |
| Power(kw) | 4 | 4 | 5.5 | 5.5 | 6.5 | 7.5 | 9 |
| Net weight(kg) | 1800 | 2000 | 2200 | 2500 | 3000 | 3500 | 4350 |
| Design pressure(MPa) | 0.245 | ||||||
| Design temperature(℃) | 139 | ||||||
